RING BLOWER, SINGLE STAGE, THREE PHASE MOTOR, 50HZ

< Back

Max volume : 0.8 to18.9 m3/min
Static pressure : -50/+60 to -350/+440 mbar
Motor : 0.18Kw 200-240/346-415V 3Ph 50Hz to 20.0 Kw 200-240/346-415V 3Ph 50Hz

Product List

Click for download product's file

RING BLOWER EHS-129



MODEL:  EHS-129
Max volume 0.8 m3/min
Static pressure -50/+60 mbar
Motor 0.18Kw 200-240/346-415V 3Ph 50HzMotor 0.18Kw 110-120/220-240V single phase 50Hz



RING BLOWER EHS-229



MODEL:  EHS-229
Max volume 1.4 m3/min
Static pressure -110/+130 mbar
Motor 0.4Kw 200-240/346-415V 3Ph 50HzMotor 0.4Kw 110-120/220-240V single phase 50Hz




RING BLOWER EHS-329



MODEL:  EHS-329
Max volume 2.4 m3/min
Static pressure -140/+140 mbar
Motor 0.75Kw 200-240/346-415V 3Ph 50HzMotor 0.75Kw 110-120/220-240V single phase 50Hz



RING BLOWER EHS-339



MODEL:  EHS-339
Max volume     2.4m3/min
Static pressure -175/+200 mbar
Motor 1.3Kw 200-240/346-415V 3Ph 50HzMotor 1.1Kw 110-120/220-240V single phase 50Hz




RING BLOWER EHS-429



MODEL:  EHS-429
Max volume 3.6 m3/min
Static pressure  -210/+220 mbar
Motor 1.75 Kw 200-240/346-415V 3Ph 50HzMotor 1.5Kw 110-120/220-240V single phase 50Hz



RING BLOWER EHS-529

MODEL:  EHS-529
Max volume 5.2  m3/min
Static pressure  -230/+220 mbar
Motor   2.2 Kw 200-240/346-415V 3Ph 50Hz

RING BLOWER EHS-629

MODEL:  EHS-629
Max volume 5.2  m3/min
Static pressure  -255/+280 mbar
Motor   3.4 Kw 200-240/346-415V 3Ph 50Hz

RING BLOWER EHS-729

MODEL:  EHS-729
Max volume 9.2 m3/min
Static pressure  -270/+300 mbar
Motor   5.5 Kw 200-240/346-415V 3Ph 50Hz

RING BLOWER EHS-829

MODEL:  EHS-829
Max volume 9.2 m3/min
Static pressure  -295/+395 mbar
Motor  7.5 Kw 200-240/346-415V 3Ph 50Hz


RING BLOWER EHS-919

MODEL:  EHS-919
Max volume 18.9 m3/min
Static pressure  -200/+190 mbar
Motor 9.0Kw 200-240/346-415V 3Ph 50Hz

RING BLOWER EHS-929

MODEL:  EHS-929
Max volume 18.9 m3/min
Static pressure  -305/+295 mbar
Motor  13.0 Kw 200-240/346-415V 3Ph 50Hz

RING BLOWER EHS-939

MODEL:  EHS-939
Max volume 18.9 m3/min
Static pressure  -350/+440 mbar
Motor  20.0 Kw 200-240/346-415V 3Ph 50Hz
