Aeroflow

Air Capacity: 0.1 - 260 m3/min
Roots Blower for Multi- Stage TRS type ---- 10,000 - 20,000 mmAq.

Air Capacity: 0.1 - 260 m3/min
Roots vacuum pump for RSV/EV type: up to -5, 000mmAq.Roots Blower for RSS type --- 0 -8,000 mmAq.
RSS-series are standard 3-lobe roots blower, its structure is very compact and have higher running reliability and  long life, the inlet sizes are from 1.5" to 14".
RSS-series can run under the pressure of 80Kpa without cooling water,    and the biggest capacity can be 260 m3/min. Our company has also developed RSW water-cooling series blower for the pressure between 80Kpa and 100Kpa. So the biggest pressure of two-stage can be 200Kpa. RSV Type BlowerRSV-series are also developed from RSS series, the biggest pressure can be -500mmHg.

Air Capacity: 0.1 - 260 m3/min
Pressure:  Roots Blower for RSW/EV type ---- 0-10,000 mmAq.
Vacuum:  Roots vacuum pump for RSV/EV type: up to -5, 000mmAq.EV Roots Blower Series
EV series 3-lobe roots blowers are researched and developed on a basis of RSS series, the biggest feature of this blower is high rotation speed( the maximum can be 4000RPM)、high capacity. With the breakthrough of technology and the modification of practical application, EV series bowers have higher efficiency、higher pressure、lower weight and other features. The inlet sizes are from 2.5”to 14”. The pressure of single blower can be 1 kilogram.



Air Capacity: 0.1 - 260 m3/min
Pressure:

EV Roots Blower Series
EV series 3-lobe roots blowers are researched and developed on a basis of RSS series, the biggest feature of this blower is high rotation speed( the maximum can be 4000RPM)、high capacity. With the breakthrough of technology and the modification of practical application, EV series bowers have higher efficiency、higher pressure、lower weight and other features. The inlet sizes are from 2.5”to 14”. The pressure of single blower can be 1 kilogram.

Air Capacity: 0.1 - 260 m3/min
Pressure:
Roots Blower for RSS type --- 0 -8,000 mmAq.
RSS-series are standard 3-lobe roots blower, its structure is very compact and have higher running reliability and  long life, the inlet sizes are from 1.5 to 14.RSS-series can run under the pressure of 80Kpa without cooling water, and the biggest capacity can be 260 m3/min. Our company has also developed RSW water-cooling series blower for the pressure between 80Kpa and 100Kpa. So the biggest pressure of two-stage can be 200Kpa.  RSV-series are also developed from RSS series, the biggest pressure can be -500mmHg.
